JBL SRX915M - 15-Inch Powered Multi-Purpose Speaker

Product Code: JBL SRX915M

Key Features
  • Single 15-inch low-frequency driver and neodymium 1.5-inch annular-diaphragm compression driver
  • 275F woofer employs JBL’s patented Differential Drive technology
  • Dual 2-inch voice coils and a ferrite magnet provide balance of output, weight, and thermal performance
  • 90° × 60° rotatable Progressive Transition waveguide ensures smooth, predictable coverage
  • LF extension reaches down to 50 Hz
  • 80 Hz high-pass preset available for applications using SRX900 subwoofers
  • 45-degree monitor angle
  • Voicing and phase response optimized to match SRX900 line-source products
  • Integrated amplification delivers plug-and-play operation
  • Rear LCD enables fast configuration
  • DSP includes 24 user-adjustable filters, 2,000 ms delay, and essential loudspeaker management tools
  • Seven M10 Quick-Link attachment points included for suspension using standard M10 eye bolts
Enquire Now
Qty Each (inc GST) Each
Estimated Lead time 8-12 weeks
  • Features
  • Overview
  • Technical Specs
  • Documents

JBL SRX915M - 15-Inch Powered Multi-Purpose Speaker

The SRX915M is a high-output, multi-purpose, two-way 15-inch powered point-source loudspeaker designed for applications that require greater low-frequency extension and increased headroom. It is ideally suited for use as a main PA or as a high-performance stage monitor. When deployed as a monitor, the enclosure’s multi-purpose design provides a 45-degree monitor angle in a low-profile package.

Multiple M10 QuickLink™ suspension points support quick and secure integration with a variety of dedicated accessories for both portable and installed sound applications. Integrated DSP and amplification provide a true plug-and-play experience, ensuring consistent, optimized performance anywhere in the world.

JBL transducers and proprietary Progressive Transition™ waveguides deliver outstanding fidelity and best-in-class SPL from an enclosure of this size. A full-featured software suite provides comprehensive control and monitoring across Windows, macOS, and iPadOS platforms.



Warranty

We offer a 5 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Frequency Range (-10dB) 50 Hz-20 kHz
Coverage Pattern 90° x 60°
Maximum SPL 134 dB
System Type Multi-purpose point-source, two-way powered
Amplifier Design Class-D
Continuous Power Rating 600 Watts | LF: 400 Watts | HF: 200 Watts
LF Driver (1) JBL 275F, 15 in diameter, dual 2.0 in diameter voice coil, ferrite Differential Drive®
HF Driver (1) JBL 2408H-1, 1 in exit neodymium compression driver with 1.5 in voice coil
Enclosure Exterior grade birch plywood, DuraFlexTM finish, two integral handholds
Suspension (7) JBL QuickLink M10 points
Dimensions (H x W x D) 666 mm x 428 mm x 367 mm
(26.2 in x 16.9 in x 14.5 in)
Net Weight (each) 24.7 kg (55 lbs)
