Input power: 15V, 1A via external power supply 110 – 230V AC
Power consumption: 1 W
Sensitivity, transition from normal to strong indication (steady green to red color light):
• Sensitivity knob in min position: 9 dB signal (1 kHz, ref 400 mA/m)
• Sensitivity knob in max position: - 22 dB signal (1 kHz, ref 400 mA/m)
• Frequency range: 300 Hz – 2000 Hz (rel -3 dB)
Indications (referencing steady green to red color shift)::
• No signal ( < -15 dB): Dark
• Weak signal (-7 to -15 dB): Soft flashing green light
• Normal signal (0 to -6 dB): Steady green light
• Strong signal (> 0 dB): Steady red light
Measurements: (W x H x T): 150 mm x 180 mm x 45 mm
Weight: 360 g
Color: Aluminum/transparent
