Picture/Display
Diagonal screen size (metric)
80 cm
Diagonal screen size (inch)
31.5 inch
Panel resolution
1920x1080p
Optimum resolution
1920 x 1080 @ 60 Hz
Brightness
350 cd/m²
Dynamic contrast ratio
500,000:1
Response time (typical)
6.5 ms
Aspect ratio
16:9
Viewing angle (horizontal)
178 degree
Viewing angle (vertical)
178 degree
Pixel pitch
0.36375 x 0.36375 mm
Display colors
16.7 Million
Panel technology
VA
Contrast ratio (typical)
4000:1
Clinical image
D-Image preset (dicom part 14 compatible)
Haze
2%
Supported Display Resolution
Computer formats
- 640 x 480, 60, 67, 72, 75Hz
- 720 x 400, 70Hz
- 800 x 600, 56, 60, 72, 75Hz
- 832 x 624, 75Hz
- 1024 x 768, 60, 70, 75Hz
- 1152 x 864, 75Hz
- 1152 x 870, 75Hz
- 1280 x 720, 60Hz
- 1280 x 800, 60Hz
- 1280 x 1024, 60Hz
- 1440 x 900, 60Hz
- 1600 x 1200, 60Hz
- 1680 x 1050, 60Hz
- 1920 x 1080, 60Hz
Video formats
- 480i, 60Hz
- 480p, 60Hz
- 576p, 50Hz
- 576i, 50Hz
- 720p, 60Hz
- 1080i, 50, 60Hz
- 1080p, 50, 60Hz
Connectivity
Video input
- DVI-I (x 1)
- HDMI 2.0 (x2)
- USB 2.0 (x2)
Audio input
3.5 mm jack
Audio output
3.5mm jack
External control
- IR (in/out) 3.5 mm jack
- RJ45
- RS232C (in/out) 2.5 mm jack
Convenience
Placement
- Landscape (18/7)
- Portrait (18/7)
Tiled Matrix
Up to 10 x 15
Signal loop through
Energy saving functions
Smart Power
Network controllable
Keyboard control
Remote control signal
Lockable
Start-up
- Switch on delay
- Switch on status
- Boot on source
Start-up window
enable / disable Philips logo
Operating conditions
Temperature range (operation)
0 ~ 40 °C
Temperature range (storage)
-20 ~ 60 °C
Altitude
0 ~ 3000 m
MTBF
50,000 hour(s)
Humidity range (operation)[RH]
20 ~ 80% RH (No condensation)
Humidity range (storage) [RH]
5 ~ 95% RH (No condensation)
Power
Consumption (Typical)
45 W
Consumption (Max)
65 W
Standby power consumption
<0.5 W
Mains power
100 - 240V~, 50/60Hz
Power Saving Features
Smart Power
Energy Label Class
G
Sound
Built-in speakers
2 x 10W RMS
Multimedia Applications
USB Playback Video
USB Playback Picture
USB Playback Audio
Dimensions
Set Width
726.5 mm
Set Height
425.4 mm
Set Depth
69.1(D@Handle) / 65.1(D@Wall mount) mm
Set Width (inch)
28.6 inch
Set Height (inch)
16.75 inch
Set Depth (inch)
2.72 (D@Handle) / 2.56 (D@Wall mount) inch
Bezel width
11.9 (TLR) / 17.2 (B) mm
VESA Mount
100mm x100mm, 200mm x 200mm, M4
Product weight
5.7 kg
Product weight (lb)
12.57 lb
