NETGEAR M4300-28G-POE+ 24-port PoE+ Layer 3 Stackable Fully Managed Switch with 2 x 10GBASE-T & 2 x SFP+ & 550W PSU

Product Code: NGR GSM4328PA-100AJS

Key Features
  • 24-port 1000BASE-T (RJ45) PoE+
  • 2-port 10GBASE-T (RJ45) all independent
  • 2-port 10GBASE-X (SFP+) all independent
  • 128Gbps non-blocking fabric across 28 ports
  • Out-of-band 1G Ethernet Management port
  • Mini-USB and RJ45 RS232 console ports and USB storage port
  • Full L3 feature set and non-stop forwarding (NSF) stacking
  • Full width form factor with one-unit rack mount kit
  • (GSM4328PA) Ships with one modular APS550W PSU in first power supply slot
  • Ship with a blank cover in the second power supply slot
$4,399.00 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Estimated Lead time 4-6 weeks
  • Features
  • Overview
  • Technical Specs
  • Documents

NETGEAR M4300-28G-POE+ 24-port PoE+ Layer 3 Stackable Fully Managed Switch with 2 x 10GBASE-T & 2 x SFP+ & 550W PSU

RELIABILITY:

Business Continuity Management - Full-width switches offer dual redundant, modular power supplies (select m4300 models)

High Availability (HA) - Non-stop forwarding (NSF) virtual chassis architectures with hitless failover across the stack

Multi-Resiliency - Stacking and distributed link aggregation allow for zero downtime and load balancing capabilities

PVST+ Interoperability - Per VLAN Spanning Tree and Per VLAN Rapid Spanning Tree (PVSTP/PVRSTP)

Link Dependency - Enables or disables ports based on link state of different ports

Advanced IPv4/IPv6 security - Malicious code detection, DHCP Snooping, IP Source Guard protection and DoS attacks mitigation



EASY TO MANAGE:

Simple GUI - Full- functional Web console (GUI) for IT admins who prefer an intuitive graphical interface

Flexible & Efficient - Line-rate Spine and Leaf topologies offer many possibilities for server rooms, branch collapsed cores, or at the edge of growing networks.

Mix & Match Stacking - Stack between 10/40 Gigabit and 1 Gigabit models using any 10G/40G port, with any media type (RJ45, SFP+, DAC cables). Vertical, horizontal, manage as one unit

Room to Grow - With PoE+, plug and play ports, and hot swap, you're ready to grow whenever you need to.

Industry Standard - SNMP, RMON, MIB, LLDP, AAA, sFlow, RSPAN and PTPv2 1-step transparent clock implementation (select M4300 models)



READY FOR AN AV OVER IP:

Zero Touch AV-over-IP - Pre-configured for Out-of-Box L2 Multicast (SDVoE-ready)

No Delay - Non-Blocking Fabric for Near-Zero Switch Latency

NETGEAR IGMP Plus™ - Prevent network flooding with effortless multicast implementation of Layer 2 Multicast



Designed for AV Pros - NETGEAR M4300 Switches

What is AV-over-IP?

Tech Tips: How to Create a Layer 2 VLAN on an M4300 switch:

How to Log in to the NETGEAR M4300 Switch Through the Command Line:

How to Log in to the NETGEAR M4300 Switch Using the Web GUI:

Warranty

We offer a Limited Lifetime warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Trade Terms
This item is a firm order product, meaning it cannot be cancelled or returned once the purchase order is processed, except in cases of defect. Please verify that part numbers and descriptions are accurate before placing your order. For any confirmation or additional information, please contact AV Sales at 1800 00 77 80.
  • Hardware Specifications : Model Number: GSM4328PA
  • PoE Budget (110V): 480W w/1 PSU, 480W w/2 PSUs in RPS mode, 720W w/2 PSUs in EPS mode
  • 24 Ports PoE+ Copper 10M / 100M / 1G
  • 2 Ports Copper 100M / 1G / 10G
  • 2 Ports SFP+ 1G / 10G
  • 2 Modular Bays with One (1) 550W Modular PSU included APS550W
  • 128 Gps Switching Fabric
  • Fixed Fan Front-to-Back 39.8dB
  • Management Options : Ethernet: Out-of-band 1G port (Front)
  • Console: RJ45 RS232 (Back)
  • Console: Mini-USB (Front)
  • Storage: USB (Front)
  • Single-pane-of-glass NMS300 management platform with mass-configuration support
  • Dual firmware image and configuration file for updates with minimum service interruption
