JBL Control 442C/T - 2.5 Inch Compact Ceiling Loudspeaker White - Priced as Each Sold as Pair

Product Code: JBL C442CT

Key Features
  • 63.5 mm (2.5 in) driver
  • Integrated enclosure that is ideal for installation in most ceiling plenum spaces
  • Built-in 70V/100V multi-tap transformer, plus 16-ohm direct input
  • Full-face, easily paintable magnetic grilles
  • Top and side cable entry options
  • Robust and adaptable dogears for wide range of ceiling thicknesses
  • IP33 rated
$281.91 inc GST
(EA)
Increase value Decrease value
Qty Each (inc GST) Each
Stock on order
  • Features
  • Overview
  • Technical Specs
  • Documents

JBL Control 442C/T - 2.5 Inch Compact Ceiling Loudspeaker White - Priced as Each Sold as Pair

The JBL Control 442C/T, part of the flagship Control 400 Premium Coverage Series, is a compact ceiling loudspeaker, featuring a 2.5” driver and an integrated enclosure that is ideal for installation in most ceiling plenum spaces.

Control 400 Series ceiling speakers boast thoughtfully engineered mounting features to enhance safety, efficiency, and repeatability. Terminal covers allow for convenient top or side cable entry and are secured effortlessly with captive hand-screws. The reliable captive dogear design accommodates a variety of ceiling thicknesses, ensuring versatility for any environment.

All models embrace design elements tailored for modern interiors. The included full-face magnetic grille is paintable for seamless integration into any decor, while available black and square grilles provide added customization. Additionally, the Control 442C/T supports both 70V/100V and low impedance applications.

PREMIUM SONIC PERFORMANCE

Featuring JBL’s proprietary Radiation Boundary Integrator® (RBI™) technology, the Premium Coverage Series achieves constant directivity coverage, ensuring that listeners can enjoy an especially smooth sound character that remains extremely consistent, clear, and pleasant across a wide coverage area.

EFFICIENT, FLEXIBLE INSTALLATION

Control 400 Series ceiling speakers are engineered to improve installation repeatability and safety while reducing installation time. Terminal covers provide both top and side cable entry ports, allowing installers to choose the best option for each application. The captive dogear design is extremely reliable and works with a wide range of ceiling thicknesses.

REFINED, MODERN AESTHETICS

Full-face magnetic grilles provide a sleek, refined look to meet the sensibilities of modern architectural design. They are equipped with safety tethers, which mount right into the baffle to ensure peace of mind. Optional black and square accessory grilles are also available to empower added design versatility.



Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Frequency Range (-10 dB) 130Hz - 20kHz
Power Capacity 22.5 W (90 W Peak), Cont. Pink Noise (2 hrs.)
15 W (60 W Peak) Cont. Pink Noise Power (100 hrs.)
Sensitivity (1m/1W) 86dB
Coverage Angle 160° conical
Maximum SPL (1m) 99.5 dB Cont. pink noise (105.5 dB peak)
Nominal Impedance 16Ω
Transformer Taps 70 V: 12 W, 6 W & 3 W
100 V: 12 W, 6 W
Drivers 60 mm (2.5 in) Full Range driver with paper cone, Rubber surround, CCAW coil
Ceiling Cutout Size 104 mm (4.1 in)
Dimensions 138 mm (5.4 in) H x 131 mm (5.2 in) dia.
129 mm (5.1 in) from bottom of ceiling tile to top of backcan
Safety Agency Rating Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.
Environmental IP rating: IP33 per EN/IEC 60529.
Operating temperature: 0° C to 45 °C.
Optional Accessories JBL-MTC-442BG black (RAL9004) round grille
JBL-MTC-442SG white (RAL9003) square grille
JBL-MTC-442NC new construction bracket
JBL-MTC-442MR mud-ring construction bracket
JBL-MTC-48TRX4 tile rail for 4' x 4' ceiling tiles
Color Stock grille is White (RAL9003), paintable
Net Weight (ea) 1.1 kg (2.43 lbs)
Shipping Weight (pair) 3.22 kg (7.1 lbs)
SKU Numbers JBL-C442C/T
