AKG P-420 DualCapsule True Condenser Microphone

Product Code: AKG 3101H00430

Key Features
  • One-inch dual-diaphragm microphone with three selectable polar patterns. For the perfect setting.
  • Low noise electronics. For high dynamic range.
  • Switchble attenuation pad. For high SPL applications up to 155 dB SPL.
Enquire Now
Qty Each (inc GST) Each
Stock on order
  • Features
  • Overview
  • Technical Specs
  • Documents

AKG P-420 Dual-Capsule True Condenser Microphone

Professional projects

The P420 is a multi-pattern large diaphragm true condenser microphone for demanding project studio recording applications. Offering high sensitivity and 155dB maximum SPL, the P420 delivers a warm, transparent sound quality perfectly suited for ensemble recording, grand piano, woodwind and brass instruments, as well as drums and percussion. With three selectable polar patterns – cardioid, omnidirectional or figure 8 – it is an ideal tool for stereo miking techniques and ambient recording.

Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Trade Terms
This item is a firm order product, meaning it cannot be cancelled or returned once the purchase order is processed, except in cases of defect. Please verify that part numbers and descriptions are accurate before placing your order. For any confirmation or additional information, please contact AV Sales at 1800 00 77 80.
Audio frequency bandwidth 20 - 20000 Hz
Equivalent noise level 15 dB-A
Sensitivity 20 mV/Pa
Signal to Noise 79 dB-A
Preattenuation Pad -20 dB
Bass cut filter 300 Hz - 12 dB/octave
Electrical impedance <= 200 Ohms
Recommended load impedance >= 1000 Ohms
Polar Pattern Cardioid, Omnidirectional, and Figure of eight

Application

Project Studio Yes

Dimensions

Length 165 mm
Diameter 54 mm
Net Weight 530 g

Audio Output

Type Balanced XLR
Gender Male
Contacts 3-pin

Powering Interface

Voltage 44 to 52 V
Current <= 3 mA

Instrument

Piano / Strings Yes
Horns / Woodwinds Yes
Drums / Percussion Yes

What's in the Box?

  • 1 x P420 Microphone
  • 1 x Spider Shock Mount
  • 1 x Metal Carrying Case
