AKG D40 Dynamic Microphone Instrument Microphone

Product Code: AKG 2815X00050

Key Features
  • Dual-thickness Varimotion diaphragm
  • Provides crisp, powerful sound in all frequency ranges
  • Highest sound pressure levels up to 156dB
  • For extreme situations without any distortion
  • Cardioid polar pattern
  • For trouble-free use in narrow stage environments
  • Rugged wire-mesh cap and sturdy die-cast metal body
  • Withstand tough day-by-day stage use
  • Integrated stand adapter and external bracket
  • For easy mounting on drums and mic stands
Enquire Now
Qty Each (inc GST) Each
Estimated Lead time 6-8 weeks
  • Features
  • Overview
  • Technical Specs
  • Documents

AKG D40 DYNAMIC INSTRUMENT MICROPHONE

Sound in motion

The D40 professional instrumental microphone with its solid all-metal body will stand up to the hardships of night-after-night onstage use with a smile. Its patented Varimotion diaphragm uses a unique laminated material to damp high resonance peaks, leading to a quantum leap in audio performance. The transducer is protected by a sturdy wire-mesh cap and can take extremely high sound pressure levels with ease.

An integrated stand adapter in combination with the included H440 mounting bracket makes the D40 a highly versatile tool for use on drums, percussion, wind instruments and guitar amps.

Warranty

We offer a 2 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Trade Terms
This item is a firm order product, meaning it cannot be cancelled or returned once the purchase order is processed, except in cases of defect. Please verify that part numbers and descriptions are accurate before placing your order. For any confirmation or additional information, please contact AV Sales at 1800 00 77 80.
Type Dynamic pressure gradient microphone
Polar Pattern Cardioid
Audio frequency bandwidth 50 - 20000 Hz
Sensitivity at 1000 Hz 2.5 mV/Pa (–52 dBV re 1 V/Pa)
Equivalent noise level 18 dB(A) (IEC 60268-4)
Max. SPL for 1 % / 3 % THD 147 dB SPL / 156 dB SPL
Electrical impedance at 1000 Hz ≥ 600 Ohms
Recommended load impedance ≥ 2000 Ohms

Dimensions

Length 104 mm
Height 79 mm
Diameter 44 mm
Net Weight 245 g

Audio Output

Type Balanced XLR
Gender Male
Contacts 3-pin

Design

Body metal
Finish dark stage blue

Instrument

Drums / Percussion Yes
Guitar Amps / Bass Amps Yes

Application

Live Instrument Yes
