Philips 49 inch X Series FHD 500nit 3.5mm Bezel to Bezel Professional Video Wall Display

Product Code: PHL 49BDL2005X

Key Features
  • Versatile videowall display
  • 49"
  • Direct LED Backlight
  • Full HD
  • 500cd/m²
$1,595.00 inc GST
(Each)
Increase value Decrease value
Qty Each (inc GST) Each
In Stock
  • Features
  • Overview
  • Technical Specs
  • Documents

Philips 49 inch X Series FHD 500nit 3.5mm Bezel to Bezel Professional Video Wall Display

Go big

Command attention with a Philips X-Line Professional Videowall Display. Crisp contrast and narrow bezels enable clear, distraction-free imaging. Whether you're running an airport or hosting a conference.

Operate, monitor and maintain with CMND & Control

Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

OPS slot allows for PC embedding without cabling

Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.

FailOver ensures content is always playing

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on.

Ultra-narrow (3.5 mm) bezels. For distraction-free images

Tiling mode. Create tiled 4K videowalls of any size

Connect two or more Philips professional displays to create a tiled videowall-without the need for external devices. A single player takes care of content, whether you have four screens or 40. 4K content is fully supported, and if you're showing that content on four screens you get the best possible dot-by-dot resolution.

Add Android processing power with an optional CRD50 module

Embed an Android System-on-Chip (SoC) in your Philips Professional Display. The optional CRD50 module is an OPS device that enables Android processing power without the need for cables. Simply slide into the OPS slot, which contains all the connections needed to run the module (including power supply).

Warranty

We offer a 3 year onsite warranty via 3rd party on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Picture/Display
Diagonal screen size (metric) 123.2 cm
Diagonal screen size (inch) 49.5  inch
Panel resolution 1920x1080p
Optimum resolution 1920 x 1080 @ 60 Hz
Brightness 500 cd/m²
Contrast ratio (typical) 1200:1
Dynamic contrast ratio 500,000:1
Response time (typical) 8 ms
Aspect ratio 16:9
Viewing angle (horizontal) 178  degree
Viewing angle (vertical) 178  degree
Pixel pitch 0.559 x 0.559 mm
Display colors 1.07 Billion
Picture enhancement Motion compens. deinterlacing
  3/2 - 2/2 motion pull down
  Dynamic contrast enhancement
  Progressive scan
Haze 3%
Connectivity:
Video input DVI-I
  VGA (Analog D-Sub)
  Component (BNC x3)
  Display Port1.2 (x1)
  HDMI 1.4 (x2)
  Composite (Share component Y)
  USB 2.0 ( x1)
Video Output DisplayPort 1.2 (x1)
  DVI-I (x1)
Audio input 3.5 mm jack
  Audio Left/Right (RCA)
Audio output 3.5 mm jack
  External speaker connection
External control RJ45
  RS232C (in/out) 2.5 mm jack
  IR (in/out) 3.5 mm jack
Other connections OPS
Convenience:
Energy saving functions Smart Power
Tiled Matrix Up to 10 x 10
Network controllable RS232
  RJ45
Signal loop through RS232
  IR Loopthrough
  DisplayPort
  DVI Loopthrough
Placement Landscape
  Portrait
Ease of installation Carrying Handles
  Smart Insert
Screen saving functions Pixel Shift, Low Bright
Control software SICP / CMND&Control
Dimensions:
Set Width 1077.6  mm
Set Height 607.8  mm
Set Depth 93.5 mm
Bezel width Top/Left: 2.3mm, Bottom/Right: 1.2mm
VESA Mount 400 mm x 400 mm, M6
Product weight 21.0  kg
Smart Insert mount 100 x100mm, 6 x M4 L6
Bezel thickness 3.5 mm (B-B)
Power:
Standby power consumption <0.5 W
Consumption (Max) 220 W
Consumption (Typical) 100 W
Sound:
Built-in speakers 2 x 10W RMS
Accessories:
Included accessories IR Cable
  IR sensor cable (1.8 m) (x1)
  RS232 daisy-chain cable
  Kit-1 (x1)
  Kit-2 (x2)
  Thumb Screw (x8)
  Remote Control & AAA Battries
  AC Power Cord
  Quick start guide
  DVI-D cable
  RS232 cable
  Edge alignment pins
