AMX NMX-NVR-N6123 - Network Video Recorder

Product Code: AMX FGN6123

Key Features
The SVSI NMX-NVR-N6123 is a network video recorder (NVR) designed to record hours of high-resolution, HD content over an Ethernet LAN
Enquire Now
Qty Each (inc GST) Each
Stock on order
  • Features
  • Overview
  • Technical Specs
  • Documents

The NMX-NVR-N6123 is a network video recorder (NVR) designed to record hours of high-resolution, HD content over an Ethernet LAN. This rack-mount NVR is compatible with all SVSI video-over-IP products and attaches to the video network at any point. The NMX-NVR-N6123 can record from any SVSI encoder (N2000, N3000, or V-Series) and uses any SVSI decoder in the same series for playback. Each video stream is recorded and played back at its original resolution. The NMX-NVR-N6123's 2RU form-factor is stackable for a high density of recorded video streams in a small footprint. SVSI's N-Command is used to control all of the product's features (including Time-Shift, Dual-Sync, and H.264 Conversions).

Time-Delayed Broadcast
Time-Shift mode allows a recording to be delayed from several seconds to several hours to coordinate between different venues. Recordings can be initiated at one location and playback started at a separate location.This feature is supported by the N2000 and N3000 Series only.

Multi-Channel Synchronous Recording
Dual-Sync mode records two separate video streams simultaneously at different resolutions and bit-rate and plays them back synchronously. This feature is supported by the N2000 Series only. Common applications for Dual-Sync mode include:

  • During a presentation, the NVR records one video stream from a camera (videoing the presenter) while the second video stream records the content that the presenter is displaying on-screen.
  • During a lecture or worship service, the NVR records two camera feeds (focused on the same event, but from different angles) and the cameras' common audio track.
  • The NMX-NVR-N6123 is ideal for educational institutions, houses of worship, or corporate campuses that want to simultaneously distribute live video through a facility and record it for future network transmission or other delivery methods.

Features

  • Record –Up to 40-hrs of 1080p video
  • Dual-Sync and Time-Shift – Features standard.
  • Supported resolutions
    • HDTV: up to 1080p
    • CG: up to 1600x1200
  • Stereo Audio – On each record channel
  • Store – To MPEG4 format at original resolution

Harman Professional University certifications required to purchase this product. Please contact your Account Manager to learn more.

Warranty

We offer a 3 year warranty on this product from its date of purchase. For more information regarding our support, repair and warranty, please download our Warranty Guide here.

Dimensions (HWD) 3.5" x 17.25" x 15.5" (8.9 cm x 43.8 cm x 39.4 cm)
Recording and Playback Streams N2000, No. Channels: 1, Recording 2 (dual), Playback Streams: 2 (dual)*; N3000, No. Channels: 10, Recording 10, Playback Streams: 10. See Data Sheet for details.
Estimated Recording Time: 1080p sources at high quality N2000, 43 hours 27 minutes; N3000, 434 hours 39 minutes. See Data Sheet for details.
Estimated Recording Time: Convert 1 hour of 720p video to MP4 N2000, 43 hours 27 minutes; N3000, 434 hours 39 minutes. See Data Sheet for details.
FG Numbers FGN6123
